Wiska 308 Combi Black Junction Box 85 x 85 x 51mm

£4.50 Ex. VAT £5.40 Inc. VAT
  • Premium Quality Junction Boxes
  • Rated for up to 4 mm² Cable
  • IP66 Rating (Waterproof & dustpoof)
SKU: 10060580
side-bar-delivery-banner
armoured-cable-sales-and-technical-banner

Wiska 308 Combi Black Junction Box 85 x 85 x 51mm – A premium range of junction enclosures. The boxes themselves carry an IP66 rating, meaning they’re waterproof and dustproof. This makes them suitable for installation in a variety of environments, both indoor and outdoor.

These boxes also include a ‘bellied’ cover, allowing for a 10% increase in space internally.

Wiska 308 Combi Black Junction Box 85 x 85 x 51mm Specifications

  • Material:  Polypropylene
  • Material sealing gasket: TPE
  • Temp. range min:  -30 °C
  • Temp. range max:  100 °C
  • Temperatures during install:  -5 °C – 60 °C
  • Protection class: IP66 / IP67
  • Glow wire test: 750 °C
  • Voltage: 400 V
  • Rated cross section: 4 mm²
  • Fixing: 4 internal openings
  • Ø cable diameter min: 3 mm
  • Ø cable diameter max: 12 mm
  • External dimensions (L x W x H): 85 x 85 x 51mm
  • Type of cable gland: M20 x 1.5mm
  • Product Colour: RAL 9001
  • ETIM-Classification EC002600

Electrical Top Tips

Our in-house electrician Dave recommends using these junction boxes when running mains power to an outhouse. These boxes are perfect for terminating and connecting cables, including the 2.5mm Armoured Cable. Remember that the CW20S glands will be required to terminate the cable into the wiska boxes. Screws are also required when attaching the boxes to a wall or structure, which are also sold separately.

If you require technical information regarding these junction boxes, please refer to the ‘Wiska Combi 308 Black Data Sheet‘. This will provide you with all technical information regarding these boxes, helping you to make an informed purchase.

If you require a quotation for larger orders, please drop our sales team an email at [email protected]. Alternatively, give us a call on 01244 288138.

Additional information

Weight 0.3000 kg
