4mm 2 Core SWA Armoured Cable

£1.82 Ex. VAT £2.18 Inc. VAT
  • 2 Core; 4mm² Cross-sectional Area
  • Suitable For Direct Burial
  • Core Identification: Blue & Brown
  • Overall Diameter: 14.7mm
Bulk Savings Available
Qty Price
0 - 60 £1.82 Ex. VAT £2.18 Inc. VAT
61 - 72 £1.78 Ex. VAT£2.14 Inc. VAT
73 - 108 £1.75 Ex. VAT£2.10 Inc. VAT
109 - 250 £1.68 Ex. VAT£2.02 Inc. VAT
251+ £1.65 Ex. VAT£1.98 Inc. VAT

Per Metre

This product is sold by the length. Simply select the number of metres you'd like to purchase.
SKU: AC-4MM-2-CORE-SWA
side-bar-delivery-banner
armoured-cable-sales-and-technical-banner

4mm 2 Core SWA Armoured Cable is a type of electrical cable used to supply mains voltage electricity for a variety of uses. As this cable is armoured, it is suitable for direct burial and is protected from mechanical and chemical hazards.

If you’re looking to terminate this cable into a junction box or device, you’ll require a CW20S outdoor gland pack or BW20S indoor gland pack. If you need to attach this cable to a wall or structure, you’ll require CC7 cable cleats.

This cable is commonly found in a range of installations including the following;

  • Garden Lighting
  • Factory Lighting
  • LED Garden Lighting
  • Electric Gates
  • Security Lighting

If you need to asses what size cable it is you require, please follow this link for our Armoured Cable Calculator.

PLEASE NOTE; this is an approximation, if you don’t know what cable size it is you require, please contact a qualified electrician so they can consult the regulations and confirm.

Specifications for 4mm 2 Core SWA Armoured Cable

  • Overall Diameter: 14.7mm
  • Current rating: 49 Amp
  • Overall Diameter: 14.7mm
  • Conductors: Stranded copper
  • Insulation: XLPE
  • Core identification: 2 Core (Brown & Blue)
  • Bedding: PVC
  • Armour/Protection: SWA (Steel wire armour)
  • Sheath/Jacket: PVC
  • Colour: Black
  • Voltage: 600/1000v
  • Operating temperature: Maximum 90°C, minimum bending 0°C
  • British Standards: BS 5467

Delivery Information

Fast, free delivery to mainland UK addresses (excluding highlands & islands) is available for as little as £5.95 plus VAT, however delivery is free on orders over £100 excluding VAT. If you require delivery notifications via text or email, please remember to include your mobile number and email address in the order. Nationwide Saturday delivery’s are also available if you call the office on 01244 288138 to talk to the sales team.

Useful Links:

Building Regulation in England covering electrical safety in dwellings;
https://www.gov.uk/government/publications/electrical-safety-approved-document-p

Additional information

Weight 0.4100 kg
Application

Primarily found within powered networks and providing mains electricity to powered devices.

Approx overall diameter (approximate size)

14.7

Approx weight per meter

0.41

Armour / Protection

Steel Wire

Bedding

PVC

BS Number

BS5467

Colour

Black

Conductors

Plain Annealed Stranded Copper

Core identification

Brown & Blue

Current Rating

49A

Description

4mm 2 Core Armoured Cable
4mm 2 Core Armoured Cable is a form of electrical cable that has the ability to supply mains electrical power to devices and networks. The cable also has more domestic uses such as being used to supply mains electricity to devices such as outdoor buildings, for example, garden sheds or out-houses, as well as being suitable for outdoor lighting circuits such as patio and decking lights.The cable construction is identified by plain annealed stranded copper being used for the conductors/cores, PVC (Polyvinyl Chloride) being used for the bedding and sheathing, cross-linked polyethylene being used for the insulation and steel wire being used for the armour. The cable is made to the British Standard of BS5467 and is BASEC Approved. Due to the steel wire armour that is within the cable protecting the insulating layers beneath, it is also used to give the cable higher pulling loads, meaning it can take the strain of being dispensed from cable drums when delivered to a building/construction site etc. The steel wire armour can also be used as a CPC (Circuit Protective Conductor) or 'natural earth' meaning that the armour itself will earth the cable.
Delivery Information

ArmouredCable.net stock & supply a large and diverse range of Armoured Cable, including sizes ranging from 1.5mm all the way up to 300mm, available with a variety of core counts. If there is a specific size or type that you are looking for but cannot see among the range we have on here, please feel free to give our sales team a call on 01244 288138, who will be happy to provide further information and assistance. ArmouredCable.net is based on Zone 1 of Deeside Industrial Park near Chester, so if you'd prefer to pick up the items you require as opposed to having them delivered, please feel free to do so as all pick ups are welcome. 4mm 2 Core Armoured Cable available for the best prices online with fast, free delivery on orders over £100 excluding VAT. A delivery charge of £5.95 will be applied to orders that are under that amount.

Insulation

Cross-Linked Polyethylene (XLPE)

Operating temperature

90°C Maximum

Product Code

6942X 4mm

Sheath / Jacket

PVC

Number of cores / size of cable

2

Standard

BASEC Approved; BS5467 Thermosetting Insulated

Voltage

600V/1000V
