3 Phase 415V Extension Lead SY Cable 5 Pin 125A X 5M
We cut the extension lead to the length you require, and with our stock we can offer fast delivery all over the UK. These extension leads are ideal for 3 phase generators, welders, transformers and all other 3 phase machinery and tools. This extension lead is made up of braided clear sy cable 2.5mm x 4 core and includes a red 125A 5 pin plug and a red 125A 5 pin connector (socket) .
Sy cable – Plain annealed flexible copper conductors, PVC insulated, extruded PVC bedding, galvanised steel wire braid armour, transparent PVC outer sheath. 300/500 volts grade generally to BS6500 and VDE 0250 class 5.
Application: Used as interconnecting cable for measuring, controlling or regulation in control equipment for assembly and production lines, conveyors and for computer units. Suitable for fixed installations or for flexible use in conditions of light mechanical stress. Can be used outdoors when protected, and in dry or moist conditions indoors.The braided screen offers the best possible protection against mechanical damage and offers a level of Electro-magnetic shielding. The galvanised coating helps protect against corrosion.
- Standards: Generally to BS6500, VDE0250
- Conductor: Class 5 flexible annealed plain copper conductors to BS EN 60228:2005 (previously BS6360), VDE0295, IEC 60228
- Insulation: PVC (Polyvinyl Chloride) Type TI 2 complying with BS EN 50363-3:2005
- Bedding: PVC (Polyvinyl Chloride) TM2 as specified in BS EN 50363-4-1:2005
- Braiding: GSWB (Galvanised Steel Wire Braid)
- Minimum coverage of braiding shall be 50%
- Sheath: PVC (Polyvinyl Chloride) conforming to TM 2 as specified in BS EN 50363-4-1:2005
- Sheath Colour: Transparent
- Voltage Rating: 300/500V
- Operating Temperature: -15°C to +70°C
- Minimum Bending Radius: 10 x overall diameter
- Short Circuit Temperature: +160°C
- Core Identification: Black with White numbers. (3 cores and above to include Green/Yellow). Coloured cores available.
- 3 Phase 415V Extension Lead SY Cable 5 Pin 125A X 5M
Call our technical sales team on 01244 288138 today for an instant quotation or if you require a few different lengths of extension leads.
